Description
Product Description :
- 1s boot up, 7s splicing, 26s heating
- Specially designed for FTTH projects
- 4 motors active V-groove design
- Small size and light weight, easy to carry
- Automatic & real-time ARC calibration
- Heating temperature and time both adjustable
- Automatic splicing and heating, easy to operate
- Apply to bare fiber, pigtails, drop cable etc.
- Suitable for FTTx, FTTH, CATV projects etc.
- Power Supply : Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V
- Electrode life : More than 4000 ARC discharges, easy to replace
- Terminal : USB 2.0 port, for software upgrading, records exporting
- Weight : 1.75Kg (including rubber bumper)
- Dimension : 200mm (L) 15m/s ×123mm (W)×95mm (H) /1.60kg (incuding battery)
- Cladding diameter : 80-150um
- Lighting : 2 powerful white LEDs
- Tension test : standard 2.0N
